The Deep Submergence Vessel NR-1 was a unique United States Navy nuclear-powered ocean engineering and research submarine. It was built by the Electric Boat Division of General Dynamics at Groton, Connecticut. It was launched on 25 January 1969, completed its initial sea trials 19 August 1969, and was home-ported at Naval Submarine Base New London. Casually known as "Nerwin", NR-1 was never officially named or commissioned. The U.S. Navy is allocated a specific number of warships by the U.S. Congress. Admiral Hyman Rickover not only avoided using one of those allocations, but he also wanted to avoid the oversight that a warship receives from various bureaus. History NR-1's missions included search, object recovery, geological survey, oceanographic research, and installation and maintenance of underwater equipment. NR-1's unique capability to remain at one site and completely map or search an area with a high degree of accuracy was a valuable asset on several occasions. Following the loss of the Space Shuttle Challenger in 1986, NR-1 was used to search for, identify, and recover critical parts of the Challenger craft. Because it could remain on the sea floor without resurfacing frequently, NR-1 was a major tool for searching deep waters. NR-1 remained submerged and on station even when heavy weather and rough seas hit the area and forced all other search and recovery ships into port. In 1995, Dr. Robert Ballard used the NR-1 and its support ship, the MV Carolyn Chouest, to explore the wreck of the HMHS Britannic, the sister ship of the RMS Titanic, which sank off the coast of Greece while serving as a hospital ship during World War I.

Deep Submergence Craft NR-1 Name:  NR-1 Builder: General Dynamics Electric Boat Laid down: 10 June 1967 Launched: 25 January 1969 Commissioned:  23 December 1957 Out of Service:  21 November 2008     Complement: 3 0fficers, 8 crewmen & 2 scientist     Displacement: 400 tons Length: 150 feet Overall 96 ft 4 in pressure hull Beam: 12 ft 6 in Speed:    surfaced 4.5 knots   submerged 3.5 knots Complement:  8 officers and 76 men

The NR-1 was deactivated on 21 November 2008 at the US Navy submarine base at Groton, Connecticut, defuelled at Portsmouth Naval Shipyard in Kittery, Maine, then sent to Puget Sound Naval Shipyard to be scrapped.

Capabilities

The NR-1 performed underwater search and recovery, oceanographic research missions and installation and maintenance of underwater equipment to a depth of almost half a nautical mile. Its features included extending bottoming wheels, three viewing ports, exterior lighting, television and still cameras for color photographic studies, an object recovery claw, a manipulator that could be fitted with various gripping and cutting tools and a work basket that could be used in conjunction with the manipulator to deposit or recover items in the sea. Surface vision was provided by a television periscope permanently installed on a fixed mast its her sail area.

NR-1 had sophisticated electronics, computers and sonar systems that aided in navigation, communications, and object location and identification. It could maneuver or hold a steady position on or close to the seabed or underwater ridges, detect and identify objects at a considerable distance, and lift objects off the ocean floor.

NR-1 was equipped with two electric-motor driven propellers and its maneuverability was enhanced by four ducted thrusters, two in the front and two in the rear. The vehicle had diving planes mounted on the sail, and a conventional rudder.

NR-1 could travel submerged at approximately four knots for long periods, limited only by consumable supplies — primarily food. It could study and map the ocean bottom, including temperature, currents, and other information for military, commercial and scientific uses. Its nuclear propulsion provided independence from surface support ships and essentially unlimited endurance.

NR-1 was generally towed to and from remote mission locations by an accompanying surface tender, which was also capable of conducting research in conjunction with the submarine. NR-1's last mother ship was the MV Carolyn Chouest, which provided towing, communications, berthing and direct mission support for all NR-1 operations. An extremely versatile platform, it was an indispensable member of the NR-1 deep submergence team. The NR-1 command was manned with thirty-five Navy personnel and ten civilian contractor personnel. NR-1 carried as many as thirteen persons (crew and specialists) at one time, including three of the four assigned officers. (The Operations Officer rode on the MV Carolyn Chouest). All personnel that crewed NR-1 were nuclear-trained and specifically screened and interviewed by the Director, Navy Nuclear Propulsion Program, Admiral Kirkland H. Donald.

NR-1 under way, with a Royal Navy Type 23 frigate in the background

Ducted thrust is visible at the stern of the NR-1 as it maneuvers
